Drill Log #2871
Site
Melbourne Regional Landfill
Well ID
V548
Date Drilled
13-Nov-2020
Responsible Person
Approved Drill Depth (mBGL)
30
Completed Drilling Depth (mBGL)
32
Well Casing Diameter (mm)
225
Surface R.L.
53.73
Easting
300025.69
Northing
5815105.74
WELL COMPLETION DETAIL

Ground/Liner Level ↓
Length of Riser
1


Well Seal Length (m)

4

↑

W
E
L
L

S
E
A
L

↓


P
L
A
I
N

P
I
P
E



Length of Plain Pipe (m)

5

Length of Gravel Above Last Perforation (m)
1
↖ Plastic Seal
Yes





Length of Gravel Below Last Perforation (m)

27



↑



G
R
A
V
E
L

↓

0


0


0


0


0


0


0


0


0


0

__________
END CAP





Length of Perforated Pipe (m)

27
WELL COMPLETION SUMMARY

Depths are measurements of Metres Below Ground Level (mBGL) - Ground Level = 0
Completed Drilling Depth (mBGL)
32
Completed Well Casing Depth (m)
32
Well Type
Gas
Location Left Clean
Yes
Well Seal Type
Clay/Bentonite
Plastic Seal Type
Bag
Well Casing Rating (PN)
16
End Cap Type
Dust Cap
Plain Pipe Start Depth (mBGL)
0
Plain Pipe End Depth (mBGL)
5
Perf Pipe Start Depth (mBGL)
5
Perf Pipe End Depth (mBGL)
32
Well Seal Start Depth (mBGL)
0
Well Seal End Depth (mBGL)
4

CUSTOMER INSPECTION/COMMONUICATION DETAILS
WASTE STREAM
Interval
Start
(mBGL)
Interval
End
(mBGL)
Waste Stream
Other
Photo Thumbail

Melbourne Regional Landfill - V548  (12 Waste records)
0 1 Capping Material
1 4 Household
4 7 Household
7 10 Household
10 13 Household
13 16 Household
16 19 Household
19 22 Household
22 25 Household
25 28 Household
28 31 Household
31 32 Household
PHOTO COMPLETE WELL
