Drill Log #3344
Site
Melbourne Regional Landfill
Well ID
W5-1
Date Drilled
10-Jan-2024
Responsible Person
Approved Drill Depth (mBGL)
34
Completed Drilling Depth (mBGL)
32.3
Well Casing Diameter (mm)
200
Surface R.L.
96.6
Easting
299268.00
Northing
5815845.51
WELL COMPLETION DETAIL

Ground/Liner Level ↓
Length of Riser
1


Well Seal Length (m)

3

↑

W
E
L
L

S
E
A
L

↓


P
L
A
I
N

P
I
P
E



Length of Plain Pipe (m)

4

Length of Gravel Above Last Perforation (m)
1
↖ Plastic Seal
Yes





Length of Gravel Below Last Perforation (m)

28.3



↑



G
R
A
V
E
L

↓

0


0


0


0


0


0


0


0


0


0

__________
END CAP





Length of Perforated Pipe (m)

28.3
WELL COMPLETION SUMMARY

Depths are measurements of Metres Below Ground Level (mBGL) - Ground Level = 0
Completed Drilling Depth (mBGL)
32.3
Completed Well Casing Depth (m)
32.3
Well Type
Gas
Location Left Clean
Yes
Well Seal Type
Clay/Bentonite
Plastic Seal Type
N/A
Well Casing Rating (PN)
16
End Cap Type
Butt Welded
Plain Pipe Start Depth (mBGL)
0
Plain Pipe End Depth (mBGL)
4
Perf Pipe Start Depth (mBGL)
4
Perf Pipe End Depth (mBGL)
32.3
Well Seal Start Depth (mBGL)
0
Well Seal End Depth (mBGL)
3

CUSTOMER INSPECTION/COMMONUICATION DETAILS

Reg confirmed change of depth with Hamid as we couldn't get any deeper.

Safe drill depth form approved by Hamid. SafeDrillDepthForm_stage 5_Rev1-FA 23 12 08 CWY.xlsx
10-01-2024 12:00 AM
WASTE STREAM
Interval
Start
(mBGL)
Interval
End
(mBGL)
Waste Stream
Other
Photo Thumbail

Melbourne Regional Landfill - W5-1  (11 Waste records)
0 0.8 Capping Material
0.8 12.5 Other Dry industrial waste. Wood, plastic, paper.
12.5 13 Capping Material
13 22.5 Other Dry industrial waste. Plastics, paper, metal.
22.5 23.5 Other Dry industrial waste and dark clay.
23.5 26 Other Dry industrial waste. Paper, plastics, metal.
26 26.5 Other Dry industrial waste and clay.
26.5 27.5 Other Dry waste, paper and plastics.
27.5 28 Capping Material
28 30 Other Dry industrial waste. Plastic, paper, wire.
30 32.3 Other Wet waste. Unable to get past 32.3m.
PHOTO COMPLETE WELL
