Drill Log #3393
Site
Melbourne Regional Landfill
Well ID
W4-31
Date Drilled
1-Feb-2024
Responsible Person
Approved Drill Depth (mBGL)
36
Completed Drilling Depth (mBGL)
32
Well Casing Diameter (mm)
200
Surface R.L.
97.87
Easting
299414.55
Northing
5815877.32
WELL COMPLETION DETAIL

Ground/Liner Level ↓
Length of Riser
1


Well Seal Length (m)

4

↑

W
E
L
L

S
E
A
L

↓


P
L
A
I
N

P
I
P
E



Length of Plain Pipe (m)

5

Length of Gravel Above Last Perforation (m)
1
↖ Plastic Seal
Yes





Length of Gravel Below Last Perforation (m)

24



↑



G
R
A
V
E
L

↓

0


0


0


0


0


0


0


0


0


0

__________
END CAP





Length of Perforated Pipe (m)

24
WELL COMPLETION SUMMARY

Depths are measurements of Metres Below Ground Level (mBGL) - Ground Level = 0
Completed Drilling Depth (mBGL)
32
Completed Well Casing Depth (m)
29
Well Type
Gas
Location Left Clean
Yes
Well Seal Type
Clay/Bentonite
Plastic Seal Type
N/A
Well Casing Rating (PN)
16
End Cap Type
Butt Welded
Plain Pipe Start Depth (mBGL)
0
Plain Pipe End Depth (mBGL)
5
Perf Pipe Start Depth (mBGL)
5
Perf Pipe End Depth (mBGL)
29
Well Seal Start Depth (mBGL)
0
Well Seal End Depth (mBGL)
4

CUSTOMER INSPECTION/COMMONUICATION DETAILS

Safe drill depth form approved by Hamid. 015-DN-027. Rev-B 25-01-2024.

Hi Hamid,

As discussed we hit leachate at around 25m on well W4-31 and couldn't get proposed depth of 36m. The well kept collapsing to around 29m so we have cut the well and installed to that depth.

Thanks Richard.

Approved.

Kind Regards

Hamid

Hamidreza Kamalan
Landfill Gas Engineer [VIC]
25-01-2024 12:00 AM
WASTE STREAM
Interval
Start
(mBGL)
Interval
End
(mBGL)
Waste Stream
Other
Photo Thumbail

Melbourne Regional Landfill - W4-31  (6 Waste records)
0 5 Capping Material

5 14 Other Dry industrial waste. Paper, fabric.
14 21 Other Moist industrial waste. Wood, plastics, foam, cardboard.
21 25 Other Moist waste. Plastics and fabrics.
25 32 Other Leachate from 25m. Waste wont stay in barrel. Hole collapsing to 29m. Cut pipe and install.
PHOTO COMPLETE WELL
