Drill Log #3451
Site
Melbourne Regional Landfill
Well ID
W4-8
Date Drilled
25-Feb-2024
Responsible Person
Approved Drill Depth (mBGL)
31
Completed Drilling Depth (mBGL)
31
Well Casing Diameter (mm)
200
Surface R.L.
90.74
Easting
299419.38
Northing
5816022.52
WELL COMPLETION DETAIL

Ground/Liner Level ↓
Length of Riser
1


Well Seal Length (m)

4

↑

W
E
L
L

S
E
A
L

↓


P
L
A
I
N

P
I
P
E



Length of Plain Pipe (m)

5

Length of Gravel Above Last Perforation (m)
1
↖ Plastic Seal
Yes





Length of Gravel Below Last Perforation (m)

26



↑



G
R
A
V
E
L

↓

0


0


0


0


0


0


0


0


0


0

__________
END CAP





Length of Perforated Pipe (m)

26
WELL COMPLETION SUMMARY

Depths are measurements of Metres Below Ground Level (mBGL) - Ground Level = 0
Completed Drilling Depth (mBGL)
31
Completed Well Casing Depth (m)
31
Well Type
Gas
Location Left Clean
Yes
Well Seal Type
Clay/Bentonite
Plastic Seal Type
N/A
Well Casing Rating (PN)
16
End Cap Type
Butt Welded
Plain Pipe Start Depth (mBGL)
0
Plain Pipe End Depth (mBGL)
5
Perf Pipe Start Depth (mBGL)
5
Perf Pipe End Depth (mBGL)
31
Well Seal Start Depth (mBGL)
0
Well Seal End Depth (mBGL)
4

CUSTOMER INSPECTION/COMMONUICATION DETAILS
Safe drill depth form approved byu Hamid. 015-DN-027. Rev-B 25-01-2024.
25-01-2024 12:00 AM
WASTE STREAM
Interval
Start
(mBGL)
Interval
End
(mBGL)
Waste Stream
Other
Photo Thumbail

Melbourne Regional Landfill - W4-8  (6 Waste records)
0 1.8 Capping Material

1.8 14.5 Other Dry waste. Plastics, wood, wire.
14.5 15 Capping Material
15 25 Other Dry general waste. Plastics.
25 31 Other Plastics, timber, medical.
PHOTO COMPLETE WELL
