Drill Log #3461
Site
Melbourne Regional Landfill
Well ID
W3-10
Date Drilled
5-Mar-2024
Responsible Person
Approved Drill Depth (mBGL)
28.8
Completed Drilling Depth (mBGL)
28.8
Well Casing Diameter (mm)
200
Surface R.L.
89.64
Easting
299649.79
Northing
5815975.06
WELL COMPLETION DETAIL

Ground/Liner Level ↓
Length of Riser
1


Well Seal Length (m)

4

↑

W
E
L
L

S
E
A
L

↓


P
L
A
I
N

P
I
P
E



Length of Plain Pipe (m)

5

Length of Gravel Above Last Perforation (m)
1
↖ Plastic Seal
Yes





Length of Gravel Below Last Perforation (m)

23.8



↑



G
R
A
V
E
L

↓

0


0


0


0


0


0


0


0


0


0

__________
END CAP





Length of Perforated Pipe (m)

23.8
WELL COMPLETION SUMMARY

Depths are measurements of Metres Below Ground Level (mBGL) - Ground Level = 0
Completed Drilling Depth (mBGL)
28.8
Completed Well Casing Depth (m)
28.8
Well Type
Gas
Location Left Clean
Yes
Well Seal Type
Clay/Bentonite
Plastic Seal Type
N/A
Well Casing Rating (PN)
16
End Cap Type
Butt Welded
Plain Pipe Start Depth (mBGL)
0
Plain Pipe End Depth (mBGL)
5
Perf Pipe Start Depth (mBGL)
5
Perf Pipe End Depth (mBGL)
28.8
Well Seal Start Depth (mBGL)
0
Well Seal End Depth (mBGL)
4

CUSTOMER INSPECTION/COMMONUICATION DETAILS
Safe drill depth form approved by Hamid. Phase 3 SafeDrillDepthForm_Rev0 28.02.24 Batch 3 CWY Checked 24 02 29.xlsx
29-02-2024 12:00 AM
WASTE STREAM
Interval
Start
(mBGL)
Interval
End
(mBGL)
Waste Stream
Other
Photo Thumbail

Melbourne Regional Landfill - W3-10  (6 Waste records)
0 5 Capping Material

5 9 Other Dry industrial waste. Plastics, cardboard, wire, rope.
9 9.5 Capping Material
9.5 25 Other Dry waste. Plastics, rope, wire, cardboard.
25 28.8 Other Dry waste. Plastics, fabrics. Clay at 25 and 27m
PHOTO COMPLETE WELL
