Drill Log #3479
Site
Melbourne Regional Landfill
Well ID
W4-3
Date Drilled
14-Mar-2024
Responsible Person
Approved Drill Depth (mBGL)
10.5
Completed Drilling Depth (mBGL)
10.5
Well Casing Diameter (mm)
200
Surface R.L.
80.86
Easting
299441.70
Northing
5816062.26
WELL COMPLETION DETAIL

Ground/Liner Level ↓
Length of Riser
1


Well Seal Length (m)

4

↑

W
E
L
L

S
E
A
L

↓


P
L
A
I
N

P
I
P
E



Length of Plain Pipe (m)

5

Length of Gravel Above Last Perforation (m)
1
↖ Plastic Seal
Yes





Length of Gravel Below Last Perforation (m)

5.5



↑



G
R
A
V
E
L

↓

0


0


0


0


0


0


0


0


0


0

__________
END CAP





Length of Perforated Pipe (m)

5.5
WELL COMPLETION SUMMARY

Depths are measurements of Metres Below Ground Level (mBGL) - Ground Level = 0
Completed Drilling Depth (mBGL)
10.5
Completed Well Casing Depth (m)
10.5
Well Type
Gas
Location Left Clean
Yes
Well Seal Type
Clay/Bentonite
Plastic Seal Type
N/A
Well Casing Rating (PN)
16
End Cap Type
Butt Welded
Plain Pipe Start Depth (mBGL)
0
Plain Pipe End Depth (mBGL)
5
Perf Pipe Start Depth (mBGL)
5
Perf Pipe End Depth (mBGL)
10.5
Well Seal Start Depth (mBGL)
0
Well Seal End Depth (mBGL)
4

CUSTOMER INSPECTION/COMMONUICATION DETAILS
Safe drill depth form approved by Hamid. 015-DN-027. Rev-1b.
06-02-2024 12:00 AM
WASTE STREAM
Interval
Start
(mBGL)
Interval
End
(mBGL)
Waste Stream
Other
Photo Thumbail

Melbourne Regional Landfill - W4-3  (7 Waste records)
0 2 Capping Material

2 4 Other Dry waste. Plastics, wood, wire, rubber.
4 4.5 Capping Material
4.5 8 Other Dry waste. Plastics, wood, wire, rubber.
8 8.5 Capping Material
8.5 10.5 Other Dry waste. Plastics, wood, wire, rubber.
PHOTO COMPLETE WELL
