Drill Log #3511
Site
Melbourne Regional Landfill
Well ID
W6-14
Date Drilled
21-Dec-2023
Responsible Person
Approved Drill Depth (mBGL)
35
Completed Drilling Depth (mBGL)
35
Well Casing Diameter (mm)
200
Surface R.L.
96.39
Easting
299290.96
Northing
5815882.26
WELL COMPLETION DETAIL

Ground/Liner Level ↓
Length of Riser
1


Well Seal Length (m)

4

↑

W
E
L
L

S
E
A
L

↓


P
L
A
I
N

P
I
P
E



Length of Plain Pipe (m)

5

Length of Gravel Above Last Perforation (m)
1
↖ Plastic Seal
Yes





Length of Gravel Below Last Perforation (m)

30



↑



G
R
A
V
E
L

↓

0


0


0


0


0


0


0


0


0


0

__________
END CAP





Length of Perforated Pipe (m)

30
WELL COMPLETION SUMMARY

Depths are measurements of Metres Below Ground Level (mBGL) - Ground Level = 0
Completed Drilling Depth (mBGL)
35
Completed Well Casing Depth (m)
35
Well Type
Gas
Location Left Clean
Yes
Well Seal Type
Clay/Bentonite
Plastic Seal Type
N/A
Well Casing Rating (PN)
16
End Cap Type
Butt Welded
Plain Pipe Start Depth (mBGL)
0
Plain Pipe End Depth (mBGL)
5
Perf Pipe Start Depth (mBGL)
5
Perf Pipe End Depth (mBGL)
35
Well Seal Start Depth (mBGL)
0
Well Seal End Depth (mBGL)
4

CUSTOMER INSPECTION/COMMONUICATION DETAILS
Safe drill depth form approved by Hamid. SafeDrillDepthForm_MRL_Phase6_Rev1.xlsx
21-11-2023 12:00 AM
WASTE STREAM
Interval
Start
(mBGL)
Interval
End
(mBGL)
Waste Stream
Other
Photo Thumbail

Melbourne Regional Landfill - W6-14  (6 Waste records)
0 0.6 Capping Material

0.6 10 Other Dry waste. Paper, plastic, textiles, metal, brick fragments, wire and soil.
10 20 Other Dry waste. Paper, plastic, textiles, metal, brick fragments, wire and soil.
20 30 Other Dry waste. Paper, plastic, textiles, metal, brick fragments, wire and soil.
30 35 Other Moist waste. Paper, plastic, textiles, metal, brick fragments, wire and soil.
PHOTO COMPLETE WELL
